356 / 418
ELECTRICAL
59
TELL TALES
COLOR
INDICATOR
REMARKS
Diesel
Pre-
Heat/Glow plug
indicator
Amber
Illuminates momentarily when ignition is switched ‘ON’ to
indicate that the glow plugs are active. It will continuously
illuminate when engine is getting preheated. Start the
engine only after the indicator goes off.
Turn Signal
Green
Indicates direction indicated by the turn signal. Blinks along
with buzzer while operating left/right turn indicator only
when ignition is switched ‘ON’.
High Beam
Blue
Illuminates when the high beam head bulbs are switched
ON or flashed.
Low
Oil
Pressure
Red
1. Illuminates momentarily when ignition is switched ‘ON’.
2. Illuminates continuously if engine oil level is less than a
pre-defined minimum level. Stop the vehicle as soon as
safety permits and switch off the engine. Check engine oil
level and top-up if required. Contact qualified TATA
MOTORS assistance before starting the engine.
Battery
charging/
engine warning
Red
Illuminates momentarily when ignition is switched ‘ON’
once is cranked, it goes OFF.
It will continuously illuminate when there is malfunction of
charging system. Contact TATA MOTORS Authorized
Service Centre
Park
Brake
cum
Low
Brake
Fluid/ABS or
EBD
Malfunction.
Red
1. Illuminates momentarily when ignition is switched ‘ON’
once engine is cranked, it goes OFF.
2. When brake fluid level is low.
3. When park brake is applied and goes OFF when it is
released
4. When ABS/EBD system has a fault.
Driver
Seat
belt warning
Red
Indicates that seat belt is not fastened when ignition is ‘ON’.
If Driver seat belt is not buckled and IGN is ON then
Telltale will be ON as initial warning with No audio chime.
If Driver seat belt remains unbuckled and vehicle speed
goes above 15 km/ hr, Then Final Warning will start with
Audio Chime and it will be continued more than 90
seconds. Driver Seat belt telltale will also start flashing
along with audio alarm during Final Warning.
Passenger
Seat
belt
warning
Red
If Co-Driver (Passenger) is present and its seat belt is not
buckled and IGN is ON then Telltale will be ON as initial
warning with No audio chime.
If Co-Driver (Passenger) seat belt remains unbuckled and
vehicle speed goes above 15 km/ hr, Then Final Warning
will start with Audio Chime and it will be continued more
than 90 seconds. Co-Driver (Passenger) Seat belt telltale
will also start flashing along with audio alarm during Final
Warning.
