1.2L REVOTRON ENGINE
19
Cylinder Head Cover :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1
Hex FL Bolt M6X25 for Ignition Coil (3Qty)
1.0 ±0. 2
2
Ignition Coil (3Qty)
3
Cylinder head Cover
4
Gasket (Cylinder Head Cover)**
5
Hex. Bolt (Cylinder Head) (8Qty)
•
4.0+0.5
185˚+5˚
6
Washer
7
Gasket (Cylinder Head)
8
Dipstick
9
'O' Ring (Oil Filler Cap)
10 Oil Filler Cap
11 Hex. FL Screw M6X22 (Head Cover) (13Qty)
1.0
12 Solenoid Valve
13 Hex FL Nut AM6 for Solenoid valve (1Qty)
1.0
14 Stud C M6X20 for OCV
1.0
Note:-
•
This Symbol indicates critical tightening torque.
