1.2L REVOTRON ENGINE
17
Intake Manifold :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 ETC to Intake Manifold (HEX FL NUT AM6) (4 Qty)
1.0
2 ETC to Intake Manifold (STUD BM6X40) (4 Qty)
1.0
3 Electronic Throttle Control
4 Grommet on intake manifold for air filter (Top)
5 MAP Sensor
6 Hex FL screw m6x12
1.0
7 Intake Manifold
8 HEX FL NYLOC NUT M8 (4 Qty)
2.0+0.3
9
HEX FL BOLT M8X30 at bottom of intake manifold on
block (1 Qty)
2.5
10 Grommet on intake manifold (Bottom)
11 Intake Manifold Stud
Note:-
•
This Symbol indicates critical tightening torque.
