1.2L REVOTRON ENGINE
81
15. Raise the vehicle off the ground and drain the
engine oil by removing the drain plug into a
suitable container.
16. Drain the engine coolant by removing drain
plug into a suitable container.
17. Remove the bottom LH and RH guard.
18. Remove the drain bolt from the transaxle.
Drain the transaxle oil from the vehicle.
19. Recover A/C compressed gas using suitable
recovery unit.
20. Remove the battery tray.
21. Remove fuse box mounting bracket bolts and
set the assembly aside for accessibility.
22. Disconnect front harness electrical connection
to engine wiring harness.
