ELECTRICAL
136
Dynamic Guidelines
NOTE
Availability of Dynamic Guidelines may vary
depends on the vehicle variant.
Incase of static guidelines, guidelines always stay
static.
In case of dynamic guidelines, guidelines will
move according to the steering wheel.
WARNINGS
1. The camera uses fish eye lens. So the size of
the objects or distance from the objects that
appear in the display may differ from the actual
distances and size.
2. In low light conditions, the screen may darken
or image may become faint.
3. If the tire sizes are changed, the position of the
fixed guidelines displayed on the screen may
change.
4. Do not apply any kind of force on the camera.
5. During rainy or snowy conditions, image may
get obscured. So in this condition, do not
depend on park aid system.
6. The camera used in the vehicle, may not
reproduce the same color of the real object.
7. The rear view camera does not display objects
that are close to or below the bumper,
underneath the vehicle, or objects out of the
camera’s field of view. The area displayed on
the screen may vary according to vehicle
orientation or road conditions.
8. In case of damage of the rear portion of the
vehicle, camera position may change. Which
causes wrong visual information on display. In
case of damage, make sure that, camera fitted
properly at the intended location.
9. In case of uneven road conditions or up –hill or
downhill conditions, do not depend on rear
view camera park aid.
10.High humidity and variation in ambient
temperature may result into condensation
inside the camera lens, which may further
result into degradation of camera video feed
on the screen. It is recommended that not to
rely on camera video feed for parking
assistance in such scenario. This phenomenon
is temporary and will be automatically
recovered with reduction in humidity and less
variation in ambient temperature.
USING CAMERA
1. As the camera is waterproof construction, do
not detach, disassemble or modify in any
manner from the actual position. This will show
in correct visual information in display.
2. Do not use camera when tailgate is open. If
tailgate is open, visual information may not be
the actual rear view of the vehicle & system
will warn with message 'Tail Gate Open,
Please close.
3. Do not attach any advertisement or styling or
any kind of stickers on top of camera. If this
happens, camera cannot provide you the
visual image.
4. Do not add any accessory, which will obstruct
camera field of view.
CLEANING CAMERA
1. Due to environmental reasons, dust, mud or
fog may accumulate on the camera lens. So
regularly clean the camera lens.
2. Use water to clean the camera lens. Do not
use extreme cold extreme hot water. Rapid
changes in temperature may brittle the camera
lens.
3. Wipe the camera lens with soft cloth.
4. Do not use hard cloth or material to wipe the
camera lens. This will cause scratches on the
camera, and leads to deteriorated visual image
on the display.
5. Do not apply organic solvent, car wax, window
cleaner or glass coat to clean the camera. If
this is applied, wipe it off as soon as possible.
6. Do not apply heavy force on lens, while
cleaning.
7. Do not remove mud, snow on the camera lens
using stick or hard material
