BODY
40
2.28 FRONT SCUFF PLATE
REMOVAL
1. Remove A pillar lower trim. (For procedure
refer A pillar removal process.)
2. Remove B pillar lower trim. (For procedure
refer B pillar removal process.)
3. Pull out front scuff plate from its location
FITMENT
For fitment follow reverse procedure of removal.
2.29 “B” PILLAR TRIMS:
REMOVAL
1. Remove door Beading.
2. Loosen and remove the lower mounting bolt of
seat belt.
3. Unlock B pillar lower trim from upper trim and
Pull out B pillar lower trim.
4. Remove front seat belt anchor mounting bolt.
5. Remove fastener and pull out B Pillar upper
trim.
FITMENT
For fitment follow reverse procedure of removal.
