BODY
32
2.20 TAIL GATE
A.
TAIL GATE REMOVAL
1. Open the tail gate.
2. Remove the C pillar trims (refer c pillar
removal procedure).
3. Disconnect the tail gate all wiring harness
located inside the “C” pillar trim and pull out
the wiring harness from outside.
4. Remove the mounting screw and remove the
gas balancer. Follow the same procedure at
other end.
5. Remove the top hinge mounting of the tail gate
by removing two mounting bolts. Follow the
same procedure at the other end and separate
the tail gate from the vehicle.
FITMENT
For fitment follow the reverse procedure of
removal.
NOTE
Ensure proper tightening torque is given to the
hinges of tailgate. For torque value refer to the
tightening torque table.
Tail gate Opening from cabin
