BRAKES
35
REMOVAL OF PAD
1. Keep the gear shifter lever in neutral position.
2. Apply the parking brake.
3. Jack the vehicle and remove the Front wheel.
4. Loosen and remove the bottom sliding pin
bolt.
5. Swing caliper as shown.
6. Remove brake pads.
ASSEMBLY:
Follow reverse procedure to assemble brake
pads. While assembly of Brake pads, ensure
caliper piston is at home position.
