DRIVESHAFT - DIESEL
7
8. LH SIDE DRIVE SHAFT REMOVAL
1. Remove Wheel Cap.
2. Loosen the front wheels Nuts.
3. Lift the vehicle.
4. Remove Front wheels.
5. Remove Mud liner front LH.
6. Apply Brake and Remove Drive shaft Lock
Nut.
7. Use allen Key and Disconnect Upper ARB
Link from Front Strut.
8. Remove ball joint (steering rack) into knuckle
using tool part no.
2702 5890 4602
.
