1.2L REVOTRON ENGINE
123
13. Remove connecting rod.
NOTE
Keep each piston and gudgeon pin as a
set, when removed.
14. Using ring expander, remove piston rings
15. Insert flywheel locking pin to lock flywheel.
16. Remove flywheel mounting bolts and then
flywheel locking pin.
17. Remove flywheel by removing six bolts.
18. Remove Crankcase Rear Cover with Rear oil
seal.
19. Turn the bench at 180˚ to remove crankshaft
from bottom side.
20. Remove the bedplate by removing the
mounting bolts.
