1.2L REVOTRON ENGINE
91
FRONT PIPE WITH PRE-SILENCER
REMOVAL
1. Remove the mounting bolts of the Intermediate
exhaust pipe at front.
2. Remove the mounting bolts of the exhaust pipe
front.
3. Remove supporting rubber hanger on the
silencer.
4. Remove front pipe with pre-silencer.
FITMENT
For fitment follow the reverse procedure of
removal.
NOTE
Use new gaskets every time while fitment
and tighten nuts and bolts to specified
torque.
CLOSED COUPLED CATALYTIC CONVERTER
1. Remove the mounting bolts of the front
exhaust pipe and disconnect front pipe.
2. Disconnect electrical connection to both
lambda sensor.
3. Remove the heat shield of CCC.
