BODY

61

9.2.41 FRONT WHEEL ARCH LINER

REMOVAL

1. Remove three mounting screw holding front

bumper from bottom.

2. Remove two mounting screw located inside

the arch liner.

3. Pry out tree clips.

4. Remove three push on nuts.

5. Remove front wheel arch liner. Repeat similar

procedure for the other side as well.

FITMENT

For fitment follow reverse procedure of removal.
