ELECTRICAL
38
REMOVAL & REFITMENT OF REVERSE LAMP
1. . Reverse Lamp
The Reverse lamps are located in the lower part
of the Rear bumper.
REMOVAL
1. Ensure all lamps in OFF condition.
2. Disconnect Reverse Lamp Connector.
3. Remove the screw mounting fastener.
4. Pull the lamp at Rear bumper to release from
take lamp out from vehicle
NOTE
REAR FOG LAMP (IF APPLICABLE)
1. Refer Reverse lamp for Removal Procedure
