ELECTRICAL
36
REMOVAL AND REFITMENT OF TAIL LAMP
REMOVAL
1. Remove plug from hole on the wheel arch
carpet.
2. Remove the nut holding the lamp and pull out
the lamp.
3. Remove the electrical connections.
4. Remove the nut holding the lamp and pull out
the Tail position trunk Lid side lamp.
5. Remove the electrical connections.
REFITMENT:
1. Connect the electrical connection
2. Aline the lamp with its locating catcher.
3. Tighten mounting the nut.
