FATC
13
2. ECON MODE
During ECON AC operation, the system automatically
cuts off compressor at a higher temperature than
normal AC. The operation can be used during mild
weather conditions for better fuel efficiency. Comfort
level may be compromised during this operation. By
pressing ECON button text will be displayed on
display.
3. MAX DEFROST BUTTON
a. This button directs the main airflow towards
windscreen for faster defrosting (It also overrides
any mode selection you may have made.)
b. When you turn off the button, the system returns
to its former settings
! CAUTION
For your safety make sure you have a clear view
through all the windows before driving
.
4. REAR WINDOW DEFOGGER/DEMISTER
This button turns the rear window demister ON or
OFF. The system automatically deactivates after 15
min of continuous operation.
5. FRESH AIR / RECIRCULATION BUTTON
A. When the recirculation Button or LED is
switched ‘ON’, air from the vehicle’s interior is
sent throughout the system.
B. When the recirculation button is switched off,
air is brought in from outside of the vehicle
(fresh mode). Whenever discomfort is felt,
switch to fresh air mode.
NOTE
1. The outside air intakes for the climate control
system are at the base of windscreen. Keep this
area clear from leaves and other debris.
2. The system should be used with recirculation
air mode for faster heat up and cool down,
however keeping the system in recirculation
mode, particularly with AC OFF, can cause the
windows fog up.
! CAUTION
It is recommended to run the vehicle in re
circulation mode to avoid clogging of air filter.
6. AIR DISTRIBUTION (MODE) BUTTON
In AUTO mode, the FATC system will regulate the
mode automatically. However, user override is
possible with the use of MODE button to select the
desired airflowmode. Each time you press theMODE
button, the display shows the mode selected.
