312 / 948
WHEELS AND TYRES
3
C. TIGHTENING TORQUES
SR.
NO
DESCRIPTION
FASTENER
TYPE
TIGHTENING
TORQUE(Kg-m)
LOCATION
1
Dome Wheel Nut
(Alloy Wheel)
For XZ & XT Variants
Conical Seating
Hexagonal Dome
Nut M14X1.5
12 – 15
2
Wheel Nut
(Steel Wheel)
For XE & XM Variants
Conical Seating
Hexagonal
Through Nut
M14x1.5
12 – 15
3
Spare Wheel Winch
Assembly To BIW
Hex. flange Nut
AM8
2.3
Spare Wheel Winch
Assembly To BIW
Hex Flange Bolt
M10X30
4.6
