C635 TRANSAXLE
34
Apply the locking patch using Mopar thread
locker.
26.Apply a uniform bead of LOCTITE®509™
Sealer or equivalent to the sealing surface of
the case.
27.Install the gear selector assembly; tighten the
bolts to 20 Nm (15 ft. lbs.).
28.Apply a uniform bead of Mopar® Threebond
RTV Sealer or equivalent to the sealing surface
of the
NEW
input shaft sealing ring.
29.Install the sealing ring to the transmission.
30.Install the Concentric Slave Cylinder (CSC) and
bolt to the transmission. Tighten the bolts to 10
Nm (89 in. lbs.) and engage the retention tabs.
31.Connect the hydraulic fitting (2) to the plastic
retainer (1).
32.Connect the hydraulic connection at the case.
