BRAKES
34
E. BRAKE FLUID DRAINING PROCEDURE
1. Open the bonnet.
2. Remove the spring band clamp at the CMC
end and hold the CMC to reservoir connecting
hose in vertically upward position to avoid any
further loss of fluid and plug the openings with
suitable cap.
3. Open the bleed screw of front caliper
(LHS),
connect the bleed tube to the bleed screw and
place the other end of bleed tube in the
container. Now drain the brake fluid from the
hydraulic circuit by pressing the brake pedal
repeatedly through its full stroke.
NOTE
Do not reuse the same drained fluid at the time of
bleeding.
Follow the same procedure of draining for other
three calipers in the sequence given below:
Front caliper
(RHS)
Rear caliper
(LHS)
Rear caliper
(RHS)
F. BRAKE LIGHT SWITCH ADJUSTMENT
1. Place the brake pedal in release position.
2. Loosen the lock nut.
3. Adjust the brake switch till the gap between the
brake switch and the switch stopper
on the
brake pedal is 2 mm.
4. After confirming gap tighten the lock nut.
