HARRIER BOOK 1

ELECTRICAL

109

4. Loosen and remove mounting screw the

tailagate handle cover with dedicated screw

panel.

REFITMENT

For refitment follow the procedure in reverse.

NOTE

1. Ensure that door handle switch connector is

fitted tightly and properly.

2. After replacing the door handle switch, check

vehicle locking/ unlocking state changes by

pressing the replaced door handle switch.

3. The smart key shall be present during door

handle switch press.

4. Connect the Diagnostics tool and clear the

DTCs.

23. IGNITION KEY (If Applicable)

1. FLIP KEY WITH REMOTE

FUNCTIONAL DETAILS

1. Unlocking all doors.

2. Approach light/ Tailgate opening

3. Locking all doors

4. Folding key blade in/out

1. Unlocking all doors

Pressing the unlock push-button (1) of remote will

unlock all the Doors.

2. Approach light

Press approach light button (2) once, low beam,

position, roof lamp will turn ‘ON’.

This feature helps to find and reach the parked

vehicle or to reach home in dark/ cloudy condition

after parking. Red LED will be flash on the remote.

To switch ‘OFF’ the approach lights, press and re-

lease the same button or it automatically turns

‘OFF’ after certain time.

Tailgate Unlatch

To unlatch the Tail gate, long press the approach

light button (2) on remote for more than 2 sec.

NOTE

Tailgate once unlatched will not get lock

automatically with

will locked by slamming
