C635 TRANSAXLE
29
30.Remove the lubricating duct by pulling upward.
NOTE:
The oil ducts are staked to the case and may
require some grinding before removal.
31.Remove the shaft oil ducts from the case using
a screwdriver or the equivalent.
10.TRANSAXLE ASSEMBLY ON BENCH
NOTE:
It is not necessary to reestablish preload shim
thickness when new bearings are installed. It is
only necessary to establish preload shim thickness
when a transaxle housing component, gear shaft,
or differential is replaced. Transmission and
Transfer Case/Manual, Adjustments
1. Install the right and left side differential bearing
races using below tools
2751 5890 2621 - Installer, Bearing Cup
