BRAKES
52
BOOSTER ASSEMBLY.
REMOVAL
1. Remove dashboard lower from driver side.
2. Remove Split pin to disconnect brake pedal
from brake booster assembly.
3. Remove clevis pin to separate booster
assembly from brake pedal.
4. Loosen and remove booster mounting nuts.
5. Position vehicle on two post lift and
disconnect battery.
6. Drain the brake fluid from the brake circuit.
(For procedure refer brake fluid draining in
this section.)
7. Disconnect the electrical connector of brake
fluid level switch.
8. Disconnect vacuum hose from brake booster.
9. Remove the spring band clamp at the CMC
end and hold the CMC to reservoir connecting
hose in vertically upward position to avoid any
