BODY
64
10.Remove lower mounting screw.
11.Remove front Bumper.
(For procedure refer
Front Bumper removal process).
12.Remove three front mounting screws as shown
in figure.
13.Remove front fender assembly.
FITMENT
For fitment follow reverse procedure of removal.
9.2.44 FRONT WIPER
REMOVAL
1. Remove Wiper Spindle Cap.
2. Loosen and remove wiper blade mounting
fastener and pull wiper arms out of wiper
spindle.
3. Remove plenum caps from plenum trim near
Driver and Co driver side wiper spindles.
4. Lift the bonnet and fix it in the stay rod.
