KRYOTEC ENGINE
84
13. Remove the mounting bolts of the compressor
support bracket and remove the bracket.
14. Remove mounting fasteners and take out the
vent hose connecting EGR.
15. Remove the oil mist separator hose.
16. Disconnect each electrical connection and
remove the engine wiring harness mounted
on the engine.
17. Remove turbocharger outlet pipe.
NOTE
Gasket not to be reused.
18. Fit LH and RH engine mounting bracket to
engine.
(LH Mounting Bracket -: 5412 5890
2401, RH Mounting Bracket -: 5412 5890
0602).
19. Mount the engine on overhauling stand
(Overhaul Stand -: 5425 5890 0605).
20. Remove lifting hook along with fuel pump
guard.
