2.
Disconnect the electrical connector form the
assembly.
3. Gently pry out the front roof lamp assembly
from the bezel roof lamp by inserting wedge.
4. Disconnect the electrical connector form the
assembly.
REFITMENT:
Carry out the fitment process in the reverse order
of the removal.
7.8 HIGH MOUNTED STOP LAMP
PINOUT DETAILS
PIN
DESCRIPTION
1
+ ve
2
Vgnd
