603 / 948
BODY
45
2.25 FRONT SEAT BELT
FOR RETRACTOR PRETENSIONER LOAD
LIMITER (RPLL)
REMOVAL
1. Fold the front seat to have easy access for the
belt removal.
2. Loosen and remove the lower mounting bolt of
seat belt.
3. Remove lower “B” pillar trim. (For procedure
refer “B” pillar trim removal procedure in Body
section.)
4. Remove front seat belt anchor mounting bolt.
5. Remove front seat belt mid mounting bolts
6. Loosen and remove the RPLL mounting bolt.
7. Remove the front seat belt assembly.
FITMENT
For fitment follow reverse procedure of removal.
