16. Remove music system (If applicable). (For
procedure refer music system removal
process in Electrical section)
17. Pull out the air vent
18.Remove floor console assembly. (For
procedure refer floor console removal
process).
19.Remove PAB Assembly (If applicable). (For
procedure refer PAB removal process in SRS
section).
20.Remove mounting screws at glow box location.
21. Remove screw at bottom and upper side glow
box and pay out glow box.
22. Disconnect the electrical connection of switch,
glove box lamp.
23. Disconnect the electrical connection of glove
box lamp and take it.
