SUSPENSION
24
10. Assemble top mount on the bearing.(ensure
top mount orientation in such a way that the
bearing lug should be inserted in the top
mount locating hole and also aligned top
mount with brake hose bracket lug as shown
in Figure).
11. Fit Hex nut (1 in fig) and tighten to 67-74 Nm
torque. Hold the piston rod by Allen key (A/F:
6 mm) to stop piston rod rotation during
tightening of nut. (Add fig.)
12. Remove spring compression tool carefully.
13. Lock the dust cover with striker cap on bottom
and with the bearing on top as shown
