60 / 71
871 Y/L 0.50 (EA)
CAB
855 L/V 0.50 (HC)
CAB
856 L/G 0.50 (HC)
CAB
18J BR 1.00 (HC) FLRYB
CAB
18J1 BR 1.00 (HC) FLRYB
CAB
140 L/R 0.50 (HC) FLRYB
CAB
73 L/P 0.50 (HC) FLRYB
CAB
841 R/W 1.50 (HC) FLRYB
CAB
845 G/O 0.50 (HC) FLRYB
CAB
869 G/L 0.50 (HC) FLRYB
CAB
183D R/O 1.00 (CS)
CAB
75 Y/L 0.50 (EA)
CAB
75B Y/L 0.35 (LW)
CAB
17A O/Y 0.35 (AR)
CAB
108B GY/R 0.35 (GI)
CAB
108 GY/R 0.75 (ALL)
CAB
17M O/Y 0.35 (AR)
CAB
805 P/L 0.50 (HC) FLRYB
CAB
848 R/O 0.50 (HC) FLRYB
CAB
47V GY 0.75 (CS)
CAB
931C BR 0.75 (CS)
CAB
75A Y/L 0.50 (CS)
CAB
841A R/W 1.50 (HC) FLRYB
CAB
841B R/W 1.50 (HC) FLRYB
CAB
AMPLIFIER
30.0 Amps
WB001
Sheet58
IGN SUPPLY
10.0 Amps
KEY-IN
5.0 Amps
INFOTAINMENT CONTROL MODULE (ICM)
IGNITION SWITCH
NR
B
A
14PP028120
14PP028093
14PP028073
24.08.18
12.06.18
11.06.18
C
14PP028135
08.10.18
EARTH
EA32
SUB WOOFER (HAS)
PASSENGER COMP FUSE BOX
formore details
Refer sheet 17
INFOTAINMENT CONTROL MODULE (ICM)
PEPS ECU
PASSENGER COMP FUSE BOX
AUDIO & INFOTAINMENT
AD0A & NV0A
PR IW TS
PR IW TS
PR IW TS
PP RELEASE
PO RELEASE
BETA II RELEASE
PHASE
DESIGN
DR4
HM 30.09
RP 30.09
TS 30.09
26
PR SK TS
SOP RELEASE
formore details
Refer sheet 16
NTS
Q501/Q502
5412 5400 0007
59
70
A3
CZ
AH
C
HC
HD
JM
JL
CS
GI
HR
HQ
ALL
OPTION
MICROPHONE
REAR VIEW CAMERA
STEERING WHEEL SWITCHES WITH AUDIO & PHONE
BRANDED AUDIO
NON BRANDED SPEAKER/TWEETER
GEN-2 INFOTAINMENT LEVEL-B
GEN-2 INFOTAINMENT LEVEL-A
AFTERMARKET INFOTAINMENT
GEN-2 INFOTAINMENT
IC-TFT
IC-SEGMENTED
ALL VARIANTS
DESCRIPTION
AMPLIFIER
CASSETTE PLAYER (AFTER MARKET)
WB414
Sheet58
EA14
TWEETER FRONT RH (HAS)
C396-A1
AMPLIFIER I/P
C396-A7
MUTE
C115Y-8
C133B-2
KEY IN
C170-2
CH2-
C170-1
CH2+
C170-3
CH1+
C170-4
CH1-
C115Y-7
C115X-3
C115Y-19
C115Y-20
C115X-4
S108
C396-B2
Key In (KLW)/ACC
C396-B1 IGN
S17
C726B-16
ACC_Relay_Output
S75
C396K-4
Battery
C396K-1
Key In
C396K-6
Illumination
C396K-2
Gnd
C648B-1
AMP Enable(On/Off)-ACC
C648A-11
GND
C648B-12
MUTE ON/OFF
S841
C648A-5
VBAT
C648B-19
FR RH TWEETER-
C648A-3
Subwoofer RH+
C648A-9
Subwoofer RH-
C648A-4
Subwoofer LH+
C648A-10
Subwoofer LH-
C648A-12
GND
C648B-8
FR RH TWEETER+
C648A-6
VBAT
C168C-1
-
C168C-2
+
