56 / 71
567 Y/L 0.50 (N)
CAB
516 Y/L 0.50 (N)
FRT
209 G/L 0.50 (N)
CAB
729B L/O 0.50 (N)
CAB
235 R/W 0.50 (N)
CAB
36S G 0.35 (ALL)
CAB
23S Y 0.35 (ALL)
CAB
12 W/G 0.50 (N)
CAB
30 V/L 0.50 (N)
CAB
462 R 0.50 (DE)
ROF
456 Y 0.50 (DE)
ROF
461 BR 0.50 (AL)
ROF
457 L 0.50 (AL)
ROF
797 BR 0.50 (GA)
SAR
798 L 0.50 (GA)
SAR
800 L 0.50 (GA)
SAL
799 BR 0.50 (GA)
SAL
358 L 0.50 (GA)
CAB
815 O/W 0.50 (GA)
CAB
729A BR 0.50 (N)
CAB
497 Y/B 0.50 (N)
FRT
513 Y/W 0.50 (N)
FRT
515 Y/G 0.50 (N)
FRT
565 Y/B 0.50 (N)
CAB
566 Y/W 0.50 (N)
CAB
508 BR 0.50 (AL)
CAB
505 L 0.50 (AL)
CAB
474 R 0.50 (DE)
CAB
501 Y 0.50 (DE)
CAB
568 Y/G 0.50 (N)
CAB
74 W/G 0.50 (N)
CAB
812 W/B 0.50 (GA)
CAB
813 B/GY 0.50 (GA)
CAB
814 W/V 0.50 (GA)
CAB
554 R 0.50 (N)
CAB
564 W 0.50 (N)
CAB
553 W 0.50 (N)
CAB
552 V 0.50 (N)
CAB
279 L 0.50 (GA)
CAB
281 BR 0.50 (GA)
CAB
277 BR 0.50 (GA)
CAB
PASSENGER COMP FUSE BOX
C001TF C001TM 37
CONTROL MODULE
RESTRAINTS
IMPACT SENSOR RH
FRONT
Occupant Detection Sensor
Co-Driver Seat Belt Switch
SOP RELEASE
PP RELEASE
PO RELEASE
BETA II RELEASE
11.06.18 14PP028073 NR
08.10.18
24.08.18
12.06.18
14PP028135
14PP028120
14PP028093
C
B
A
RSOA
5412 5400 0007
RP 30.09
TS 30.09
PR IW TS
RESTRAINTS
55
70
A3
OPTION CODE TABLE
PAB INITIATOR,DAB INITIATOR
AIRBAG(SRS),PAD SW,PAD DISPLAY,AIRBAG ECU
SIDE AIRBAG LH & RH
DRIVER CURTAIN AIRBAG
PASSENGER CURTAIN AIRBAG
ALL VARIANTS
DESCRIPTON
Q501/Q502
N
GA
DE
AL
ALL
OPTION
HM 30.09
PHASE
DESIGN
PR IW TS
PR IW TS
PR IW TS
DR4
23
NTS
sheet 70 for XZ
sheet 69 for XT
sheet 68 for XM
sheet 67 for XE
Refer CAN
RESTRAINTS CONTROL MODULE
10.0 Amps
SIDE AIRBAG INITIATOR LH
CURTAIN AIRBAG INITIATOR LH
CURTAIN AIRBAG INITIATOR RH
for more details
Refer sheet 16
SIDE AIRBAG INITIATOR RH
RH BELT PRETENSIONER
C001SBM C001SBF 2
IMPACT SENSOR RH
SIDE
POWER INTERFACE ASIC
SQUIB ASIC
RSU INTERFACE ASIC
C001MM C001MF A6
C001MM C001MF A5
C001MM C001MF A7
C001MM C001MF A8
C001TF C001TM 33
C001TF C001TM 38
C001TF C001TM 34
IMPACT SENSOR LH
FRONT
Airbag Chassis Earth
EA27
SQUIB ASIC
C001SAM C001SAF 2
C001SBM C001SBF 1
C001SAM C001SAF 1
AIRBAG INITIATOR
PASS FRONT
IMPACT SENSOR LH
SIDE
CLOCKSPRING
AIRBAG INITIATOR
DRIVER FRONT
C209-1
C109-1
C217-2
C176A-1
V CAN H
C176A-2
V CAN L
C109-2
C176A-7
C217-1
C176A-10
CoDrvSeatBeltSig
S36K
S23K
C228-2
C328-1
C328-2
C327-1
C327-2
C115X-12
C208-2
C228-1
C208-1
C325-2
C325-1
C176B-13
-ve
C176B-6
-ve
C176B-5
+ve
C176B-18 +ve
C176B-17 -ve
C176B-19
+ve
C176B-20
-ve
C176B-7
-ve
C176B-8
+ve
C176A-23
GND
C176B-10
-ve
C115X-11
C176A-12
IGN
C209-2
C229-1
C229-2
C321-2
C182B-2
C182B-1
C176A-18
-ve
C176B-9
+ve
C176B-11
-ve
C176B-12
+ve
C176B-16
-ve
C176B-14
+ve
C176B-15
+ve
C176A-16
+ve
C176A-15
-ve
C176A-17
+ve
C176A-19
-ve
C176A-20
+ve
C321-1
C322-2
C322-1
C226-2
C182C-1
C206-2
C226-1
C182C-2
C206-1
