BODY

25

13.Disconnect the electrical connections.

14.Remove the mounting screw of rear fog lamp

and take it out.

FITMENT

For fitment follow the reverse procedure of

removal.

2.9 FRONT DOOR

REMOVAL

1. Remove electrical connection of door wiring

harness.

2. Remove Check-strap from front door

assembly in full open condition - By removing

one MTG screw from body side

.
