C635 TRANSAXLE
25
10.Remove the long case bolts and the short case
bolts.
11.Separate the case halves by carefully prying on
the gear side half and the clutch housing side
half.
12.Remove the reverse idler gear assembly.
13.Remove the shifter fork pivot pin.
14.Remove the 1-2-5-6 gear shifter fork assembly.
15.Remove the shifter fork pivot pin.
16.Remove the 3-4-reverse gear shifter fork
assembly.
17.Remove rear bearing retention bolt on shafts by
interlocking shafts using input shaft Lock Plate.
a. Remove output shaft bearing retention bolt by
roataing in clockwise direction
b. Remove Input shaft bearing retention bolt by
roataing in Anti-clockwise direction
