SUSPENSION
17
6.7.3 REMOVAL AND INSTALLATION OF
WHEEL HUB
REMOVAL:
1.
Place the vehicle in the two-post lift and apply
parking brake.
2.
Remove wheel rim cover.
3.
Loosen the wheel mounting bolts.
4.
Lift the car till the front wheels are off the
ground.
5. Unscrew the wheel mounting bolts and remove
the wheel.
6.
Unscrew and remove tie rod ball joint nut
7. Remove tie rod ball joint using puller part No.
2871 5890 4601.
8. Support the lower arm from bottom.
9. Hold hub assembly with holder part No. 2702
5890 3301.
10. Unstake and unscrew drive shaft nut and take
out the thrust washer.
11. Remove holder from the hub assembly.
a) Remove the caliper housing from the knuckle. .
