BODY
10
Installation :
1. Insert the trunk lid latch cable and lock cable
in the hook and insert the cable lock in the
groove.
2. Refit the mounting fasteners of latch.
3. Refit trunk lid carpet taps buttons.
7. Microphone :
Removal :
1. Press the microphone from topside of roof
liner by putting fingers.
2. Pull out the microphone by holding snap ring
at roof liner top.
3. Remove the connection from roof wiring
harness.
4. Takeout the microphone clip.
Re-fitment :
1. Insert and hold the snap clip on top of roof
liner.
2. Connect microphone with wiring harness
connector.
3. Insert and press the microphone to fit on liner.
