353 / 1232
ENGINE 1.3L QUADRAJET (90PS)
16
D. AIR FILTER ASSY – REMOVAL
1. Disconnect the Air flow sensor (1) and remove
the hose by loosening the hose clamp (2).
2. Lift the air filter assembly from front and move it
forward to remove it from the rear locater.
REINSTALLATION
1. Align theAir filter Assembly at the rear locator (2).
2. Press the Air filter Assembly at the front locator
pins (1) to lock it.
3. Fix the hose and tighten the clamp.
4. Connect the Air Flow Sensor.
