ELECTRICAL
47
FRONT AND REAR WIPER SYSTEM
FRONT WIPER MOTOR
LOCATION:
The front wiper motor assembly is fitted on
windscreen support panel.
FRONT WASH AND WIPE
SELF RETURN
OFF
INTERMITTENT
LOW SPEED (Not controlled by BCM)
HIGH SPEED ((Not controlled by BCM)
REAR WIPER MOTOR (If Applicable)
LOCATION:
It is fitted on tail gate panel.
REAR WASH AND WIPE:
Rear Wipe & wash ON
Rear Wipe ON
OFF
Rear Wipe & wash ON
For detail, please refer BCM section.
