BODY
29
1.4.13. FRONT DOOR GLASS AND WINDOW
WINDING MECHANISM
REMOVAL
1. Before starting to remove first lower the
window glass.
2. Remove the door trim.
(For procedure refer
door trim removal procedure.)
3. Open the front door and loosen and remove
mounting screw of the outer belt.
4. Remove the outer
belt
of door window.
5. Loosen the window winding mountings.
6. Remove electrical connection of window
winding motor.
7. Remove Window regulator rail with Motor
assembly from Door assembly.
8. Remove three mounting bolts of window
winding motor.
9. Remove the motor assembly with gearbox
from the rail.
FITMENT
For fitment follow the reverse procedure of
removal.
NOTE
During fitment of front door glass first fit the
window winding motor.
