STEERING
27
1.6. TUNING DATA SELECTION
In order to selection the correct turning data for the vehicle, TML need to be explicitly write the tuning selection
data at their EOL, otherwise no motor output from EPAS system, and system will go to error state, the error
lamp will be on. This needs to be done in order to verify the selection. Only in the next ignition cycle, the
selection will be active.
Tuning variant selection for fresh ECU – TML EOL Procedure
1.7.
CONFIGURATION SELECTION
According to TML Requirement for ABS/Non ABS & TCU/Non-TCU shall be selected by diagnostic tools. The
corrected selection can be avoid the fault information from the CAN network.
DID value and description
6214
00
Non ABS & Non TCU Variant
6214
01
Non ABS & TCU Variant
6214
02
ABS & Non TCU Variant
6214
03
ABS & TCU Variant
6215
00
Petrol
6215
01
Diesel
