SUSPENSION
31
3. Place the knuckle assembly over the hub.
Using drift part No. 2576 5890 4401 press the
knuckle assembly on the hub.
1.9.4. REMOVAL OF SUBFRAME ASSEMBLY
1. Remove the front wheel and disconnect the
anti roll bar joint.
2. Disconnect the steering tie rod ball joint from
the knuckle.
3. Disconnect the EPAS. (steering group)
4. Remove the C mount of the engine from the
Subframe.
5. Remove Exhaust Front Pipe Assy
(for Petrol).
6. Loosen the Subframe bolts and lower the
assembly (Subframe, antiroll bar, steering
rack, lower arm).
7. Remove the steering rack assembly from
Subframe.
8. Remove the anti roll bar from Subframe.
