TRANSAXLE TA6300
30
A. INPUT SHAFT DISASSEMBLY
1. Fix input shaft assembly on vice with adaptor
bush. & remove Locking Screw.
2. Install support plate 5438 5890 2602.
3. Place input shaft assembly on hydraulic press
with support plate & press input shaft as
shown. Hold input shaft from bottom.
4. Take out 6
th
5
th
gear, gear bushes, synchro
cones, needle cage, shifter sleeve & support
plate separated from input shaft from press.
5. Remove 4th gear, needle cage by pulling
synchronizer sleeve.
6. Remove snap ring & take out engaging gear.
7. Remove 3rd gear, needle cage by pulling
synchronizer sleeve.
NOTE: Inner Race of cylindrical roller bearing
will be remain on input shaft.
