298 / 1265
1.5L REVOTORQ ENGINE
43
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
26
Hex. Flange Bolt M6x45 (Qty. 4)
1.0 + 0.2
27
Assy. Vacuum Modulator (Qty. 2)
28
Hex. Flange Nut Am6 (Qty. 4)
1.0 + 0.2
29
Hose T Connector To Air Intake Hose
30
Hose EVRV To T-Connector
31
Hose EVRV To T-Connector
32
Cap Screw M8x20 (Qty. 2)
2.0
33
Gasket (Elbow For EGR Valve To Cyl.
Head)
34
Stud Cm6x25 (Qty. 2)
35
Hex. Flange Nut Am6 (Qty. 2)
1.0 + 0.2
36
Elbow (For EGR Valve)
37
Gasket (Elbow to EGR Valve)
38
Gasket (IC Pipe To Intake Manifold)
39
EGR Tube Assy
40
Hex. Flange Screw M8x14 (Qty. 2)
2.0 + 0.3
41
Gasket (IC Pipe To Intake Manifold)
42
Elbow, Air Intake
43
Stud Cm8x25 (Qty. 2)
2.0
44
Hex. Flange Nut Am8 (Qty. 2)
2.0
45
Hex. Flange Nut Am6 (Qty. 3)
1.0 + 0.2
46
Stud C M6x20 (Qty. 3)
1.0 + 0.2
47
Water Box
48
Hex. Flange Nut Am6 (Qty. 4)
1.0+0.2
49
Thermostat Assy.
