1.5L REVOTORQ ENGINE
39
Engine Suspension
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
A Mount
02
Hex. Flange Bolt M10x45 (Qty. 3)
pre-torque: 3.2
2) 6.1-6.6
03
Harden Washer (Qty. 2)
04
Hex Flange. Bolt (Front Pulley) (Qty. 2)
6.1-6.6
05
Washer Plain (Qty. 3)
06
Hex. Flange Bolt M12x65
pre-torque: 5.5
2) 10.7-11.2
07
Stud B Mount (Qty. 2)
08
Hex. Flange Nut Am12x1.25 (Qty. 2)
pre-torque: 5.5
2) 10.7-11.2
09
Hex. Flange Screw M8x12 (Qty. 2)
2.0-2.5
10
Reinforcement Plate
11
Screw M10x1.25x30 (Qty. 2)
6.1-6.6
12
Harden Washer 10.5 (Qty. 2)
13
B-Mount Assy, Engine
14
Reinforcement Plate
15
Hex. Flange Screw M8x12 (Qty. 2)
2.0-2.5
16
B-Mount Bracket
17
Socket Head Cap Screw (Qty. 2)
2.0-2.5
18
Reinforcement Plate
19
Hex. Flange Screw M10x30
6.1-6.6
20
Hex. Flange Nut Am12x1.25
21
Hex Flange Bolt (Conical)
10.7-11.2
22
C-Mount
