1.2L REVOTRON ENGINE
131
3. Remove the heat shield lower mounting bolts
and remove the heat shield.
4. Remove the lower mounting bolts of the CCC.
5. Remove the upper mounting bolts of the CCC
and take out the assembly.
6. Remove the hose connecting turbocharger to
EVRV.
7. Remove the turbocharger coolant intake and
return lines.
