BODY

53

4. Remove six Push on Nuts.

5. Remove front wheel arch liner.

FITMENT

For fitment follow reverse procedure of removal.

1.4.40. REAR WHEEL ARCH LINER



REAR WHEEL ARCH FRONT

REMOVAL

1. Remove Clip mounting Rear wheel arch liner

front.

2. Remove Push on Nuts as shown in figure.

3. Remove three Rear Bumper mounting screw.

4. Remove Rear wheel arch front.

FITMENT

For fitment follow reverse procedure of removal.
