TRANSAXLE TA6300
27
8. Remove Hex FL bolt M8x25 & take out Top
Cover Assy. with cable Mounting. Bracket.
9. Remove Oil Seal of drive shaft.
10. Remove DETENT ASSY (SHIFTER SHAFT)
as shown & take out housing, Rear half.
11. Remove Hex FL bolt M8X25 for Reverse Idler.
12. Remove snap ring on deep groove ball
bearing as shown
13. Remove three Hex FL Bolt M8X45.from inside
from front housing half.
14. Remove Hex FL Bolt M8X45 (13 nos).
