295 / 1133
1.5L REVOTORQ ENGINE
40
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
23
Hex Flange Bolt (Conical)
10.7-11.2
24
Hex. Flange Screw M10x30 (Qty. 2)
6.1-6.6
25
Bracket Assy, C-Mount
26
Hex. Flange Screw M10x30 (Qty. 4)
4.0-4.5
27
Bracket (Engine Mtg. Arm)
28
Hex. Flange Bolt M8x80 (Qty. 2)
2.9 + 0.3
29
Hex. Flange Bolt M8x35
2.9 + 0.3
30
Harden Washer (Qty. 2)
31
Hex. Flange Bolt (Qty. 2)
6.1-6.6
32
Hex. Flange Screw M8x16 (Qty. 2)
2.0-2.5
33
Reinforcement Plate
34
Hex. Flange Bolt M8x30
2.9 + 0.3
35
Rubber Stopper
36
Stopper Bracket C Mount
37
Hex Thin Nut M12
4.0-4.5
