1.5L REVOTORQ ENGINE
37
Piston, Crankshaft and Component
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Piston Top Ring (Qty. 4)
02
Piston Ring, Second (Qty. 4)
03
Oil Ring (Qty. 4)
04
Circlip Piston Pin (Qty. 8)
05
Bearing Half, Conn Rod, Upper (Qty. 4)
06
Bearing Half, Conn Rod, Lower (Qty. 4)
07
Connecting Rod Assy. (Qty. 4)
08
Bolt (Connecting Rod) M8x45.2/44.8(Qty. 8)
4.5-4.8
09
Crankshaft
10
Woodruff Key
11
Thrust Washer Lower Half (Qty. 2)
12
Main Brg Half, Lower (Qty. 5)
13
Cylindrical Pin
14
Flywheel Assy High Inertia
15
Hex. Bolt (For Flywheel) M10x18 (Qty. 6)
5.0
16
Cylindrical Pin (For Clutch) (Qty. 3)
17
Thrust Washer Upper Half (Qty. 2)
18
Main Brg Half, Upper (Qty. 5)
19
Gudgeon Pin (Qty. 4)
20
Piston Assy (Qty. 4)
Note :
•
This Symbol indicates critical tightening torque.
