1.5L REVOTORQ ENGINE
21
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
25
Bracket (For Egr Cooler Pipe)
26
Hex Flange Screw M6x10
27
TC Oil Return Line
28
Hex Flange Screw M6x18 (Qty. 2)
1.0 + 0.2
29
Gasket (TC Oil Return Line )
30
Oil Feeder Line Assembly. (Cyl. Head To
TC)
31
Sealing Washer10x14 (Qty. 4)
32
Pipe Union Bolt (For Oil Feeder) (Qty. 2)
2.0
33
Hex Flange Screw M6x18 (Qty. 2)
1.0 + 0.2
34
Gasket (TC Oil Return Line To Block
35
Gasket, Piston Cooling Nozzle (Qty.4)
36
Nozzle Assembly, Piston Cooling Piston
Cooling (Qty.4)
37
Cap Screw M5x10 (Qty.4)
0.8
38
Assembly. Hose (Return Line)
39
Spring. Band Clamp 27dx12w
40
Hex_Screw_M8x25 (Qty. 2)
2.0
41
Elbow Assembly (Water Intake)
42
Gasket (Water Inlet Elbow)
