1.5L REVOTORQ ENGINE
18
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
21
Assy. Fuel Pr. Line (Rail To Injector) (Qty.
4)
*
2.5 with
sleeve or
3.0 without
sleeve
22
Gasket (Intake Manifold)
23
Cap Screw M8x35 (Qty. 3)
2.0 + 0.3
Note:-
•
This Symbol indicates critical tightening torque.
*
Cap connector for fuel pressure line M14x1.5 (H.P. line with sleeve)
*
Cap connector for fuel pressure line M14x1.5 (H.P. line without sleeve)
