HVAC
8
SR
NO.
DESCRIPTION
FASTENER
TIGHTENING
TORQUE (N-m)
LOCATION
6A
TUBE
ASSY,LIQUID
LINE
M6 X 16
6 - 8
6C
DISCHARGE
HOSE ASSY -
1.5L
M6 X 20
6 - 8
7 Pressure switch
–
6 - 8
8
Compressor Pipe
joints
Hex FL nut AM6
TS17430-8-
SS8451S2Y
6 - 8
