ELECTRICAL
41
1.7.12 REVERSE LAMP
LOCATION
The Reverse lamp is located in the lower part of
the Rear bumper.
REMOVAL
1. Remove Rear bumper
2. Ensure all lamps in OFF condition.
3. Disconnect Reverse lamp Connector.
4. Remove Reverse lamp locking clip.
REFITMENT
For refitment follow the procedure in reverse.
